ZXM09 WEIGHTLESSNESS MEASUREMENT CONTROLLER



Features:

● 16 channel switch input and output control (6 inputs/10 outputs), with customizable port positions

● The switch quantity testing function facilitates the debugging of the batching scale

● One sensor input and one analog input (where analog input is optional)

● Fully automatic control, continuous batching process without manual intervention

● Flexible and diverse control methods, which can be controlled through instrument keyboards, switch values, and serial communication

● Dual PID regulation, two analog outputs (one of which is optional)

● Can perform quantitative control, dual serial port function (optional additional board function)

● Full panel digital calibration, which can be manually calibrated by inputting millivolts (without weight calibration function)

● Multiple digital filtering function, analog output testing and calibration function, PROFIBUS bus function

● It can be widely used in industries such as plastics, food, and chemicals that require continuous weight loss control of ingredients
