DZX8800T WEIGHING CONTROL TRANSMITTER

Features:

● The rail-clamping weighing transmission module, supports:scale calibration, zero clearing, peeling, etc.

● Support preset point output control and delay holding function

● OLEO display, which can be encrypted and closed, is suitable for all resistance strain type load cell

● Digital calibration of all-round board, simple process, convenient and intuitive

● Digital filtering function, automatic zero tracking function, power-on automatic zero clearing function

● Two-way isolated serial port function, with RS485, convenient to communicate with the upper computer

● The weighing display can be calibrated through the serial port (the serial calibration switch is turned on)

● Multi-mode optional interface functions: PROFIBUS bus, analog output, network port and serial port

● It is suitable for controlling the batching process in storage tanks and reaction kettles, concrete, asphalt, feed, metallurgy, chemical industry and other industries
