DZXL

DZXL

DZXL


Features:

● Spoke Type Load Cell

● Alloy steel, nickel plating

● Tension & Pressure sensor

● High protection level

● Easy and fast installation


Application

● material testing machine

● truck scale

● large hopper scale


Capacities

● 50 kg , 100 kg , 200 kg , 250 kg , 500 kg

● 1 t , 2 t , 3 t , 5 t , 10 t , 15 t , 20 t , 30 t , 1 tME , 30 tME


Specifications

  RATED OUTPUT
2.0±10% mV/V
  INPUT IMPEDANCE
1400Ω(20kg~1t) / 700Ω(1~30t)
  ACCURACY CLASS
10kHz
  OUTPUT IMPEDANCE
1400Ω(20kg~1t) / 700Ω(1~30t)
  NONLINEARITY
±0.05%
  INSULATION IMPEDANCE
≥ 5000MΩ
  HYSTERESIS
±0.05%
  REPEATABILITY
±0.05%
  ZERO BALANCE
±1%
  TEMP. COMPENSATED
-10 ~ +40℃
  CREEP
±0.05%
  SAFE TEMP. RANGE
    -20 ~ +80℃
  TEMP. EFFE CT ON PUTPUT
±0.05% / 10℃
  RATED EXCITATION
5~12V
  TEMP. EFFECT ON ZERO
±0.05% / 10℃
  MAXIMUM EXCITATION
15V
  CABLE LENGTH
Φ5x3m  SAFE OVERLOAD
150%
