LCT6(4A) SIGNAL AMPLIFIER

Features:

● Made of aluminum alloy shell, with input power reverse protection and output short circuit protection

● Built in constant current supply bridge, voltage current conversion, impedance adaptation, etc

● The MV signal of the resistance strain sensor can be amplified into a standard current and voltage signal output

● Can directly receive and process control systems such as AD modules of peripheral PLCs

● Four independent channels with strong load capacity can be connected to four 350 Ω sensors

● Electronic components have high response frequency, good long-term stability, and a comprehensive accuracy of ± 0.05% FS

● Applied to weighing of material cans, inspection weighing, packaging equipment, lithium battery infusion machine equipment, etc; Coating machine tension test; Machine tool pressure testing, stress testing of bridges, etc
